TrekÉmonda SLR 9 AXS
Questions and Answers
General
- Frame Ultralight 800 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle
- Weight*56 - 6.75 kg / 14.89 lbs
- Maximum Weight AllowedThis bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg).
Brakes
- Brake SRAM Red AXS hydraulic disc, flat mount
- RotorsSRAM CenterLine X, centerlock, round edge, 160mm | Max brake rotor sizes: 160mm front & rear
Wheels & Tires
- TiresBontrager R3 Hard-Case Lite, aramid bead, 120 tpi, 700x25mm / Bontrager R4 320, 700x25mm * / Pirelli P Zero Race, 120 tpi, tubeless compatible, 700x26mm *
- Rear AxisBontrager Switch thru axle, removable lever
- Front Axis Bontrager Switch thru axle, removable lever
- Rear Wheel Bontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 142x12mm thru axle
- Front WheelBontrager Aeolus RSL 37, OCLV Carbon, Tubeless Ready, 37mm rim depth, 100x12mm thru axle
Cockpit
- Stem, Size 47, 50: Bontrager Aeolus RSL Integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width, 80mm stem length / Bontrager Aeolus RSL integrated bar/stem, OCLV Carbon, Di2 routing, 100mm reach, 124mm drop, 38cm width
- Tape Bontrager Supertack Perf tape
Groupset
- Chain / BeltSRAM RED D1, 12 speed
- CrankSRAM RED AXS w/ power meter, 48/35, DUB, Size 47: 165mm length, Size 50, 52: 170mm length, Size 54, 56, 58: 172.5mm length, Size 60, 62: 175mm length
- CassetteSRAM XG-1290, 10-33, 12 speed
- Shifters SRAM RED eTap AXS, 12 speed
- Bottom Bracket SRAM DUB, T47 threaded, internal bearing
- Rear Derailleur SRAM RED eTap AXS, 36T max cog
- Front Derailleur SRAM RED eTap AXS, braze-on
- GearingSRAM RED eTap AXS, Orbit chain management, 33T max cog
Saddle
- Saddle, Size 47, 50, 52, 54, 56, 58, 60, 62: Bontrager Aeolus Pro, carbon rails, 145mm width, Size 47, 50, 52: Aeolus RSL, carbon rails, 155mm width / Bontrager Aeolus P2 Pro, carbon rails, 155mm width *, Size 54, 56, 58, 60, 62: Aeolus RSL, carbon rails
- Seat PostBontrager carbon seatmast cap, 20mm offset, Size 47, 50, 52, 54: short length, Size 56, 58, 60, 62: tall length
Suspension
- Fork Emonda SLR full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle
Disclaimer
Deviations between specified and installed components are possible depending on the delivery situation. Alternatively installed components correspond to the quality level of the specified components. The specified model year corresponds to the model series defined by the manufacturer and not necessarily the year of manufacture. As some models are produced unchanged over several years, the year of manufacture may vary. Irrespective of this, you will receive a current product in accordance with the stated specifications. Errors and omissions are excepted.
