TrekSupercaliber 9.8 GX AXS Gen 1

Loading..

Questions and Answers

Carbon
SRAM GX Eagle AXS
29"
Diamond
Disc Brakes
Buy the trek at BikeExchange, your Marketplace for all things bike!

General

  • Frame OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel
  • Weight*M - 23.15 lbs / 10.5 kg (with TLR sealant, no tubes)
  • Maximum Weight AllowedThis bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

    • Brakes

  • Brake SRAM Level TLM hydraulic disc
  • RotorsSRAM CenterLine, 6-bolt, round-edge, 160mm / SRAM CenterLine, 6-bolt, round edge, 180mm * | Max brake rotor sizes - Frame: 160mm, Fork: see fork manufacturer

    • Wheels & Tires

  • Tires Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120 tpi, 29x2.20''
  • Rear AxisBontrager Switch thru axle, removable lever
  • Rear Wheel Bontrager Kovee Pro 30 carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, SRAM XD driver, Boost148, 12mm thru axle
  • Front Wheel Bontrager Kovee Pro 30 carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle

    • Cockpit

  • StemBontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, Size S: 60mm length, Size M, M/L: 70mm length, Size L, XL: 80mm length, Size XXL: 90mm length
  • GripsESI Chunky
  • Headset Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
  • HandlebarBontrager Kovee Pro, OCLV Carbon, 35mm, 5mm rise, 720mm width

    • Groupset

  • Chain / BeltSRAM GX Eagle, 12 speed
  • CrankSRAM GX Eagle Carbon, DUB, 32T alloy ring, 52mm chainline, Size S: 170mm length, Size M, M/L, L, XL, XXL: 175mm length
  • Cassette SRAM Eagle XG-1275, 10-52, 12 speed
  • Shifters SRAM GX Eagle AXS, 12 speed
  • Bottom BracketSRAM DUB, 92mm, PressFit
  • Rear Derailleur SRAM GX Eagle AXS
  • GearingSRAM GX Eagle AXS

    • Saddle

  • SaddleBontrager Verse Elite, austenite rails, 145mm width
  • Seat PostBontrager Pro, OCLV Carbon, 31.6mm, 0mm offset, Size S: 330mm length, Size M, M/L, L, XL, XXL: 400mm length

    • Suspension

  • Fork Fox Performance 32 Step-Cast, Float EVOL air spring, GRIP 2-position damper, remote lockout, tapered steerer, 44mm offset, Boost110, 15mm Kabolt axle, 100mm travel
  • ShockTrek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235mm x 32.5mm
  • Fork typesuspension fork
  • Front suspension100mm
  • Fork ManufacturerFox
    • Disclaimer

    Deviations between specified and installed components are possible depending on the delivery situation. Alternatively installed components correspond to the quality level of the specified components. The specified model year corresponds to the model series defined by the manufacturer and not necessarily the year of manufacture. As some models are produced unchanged over several years, the year of manufacture may vary. Irrespective of this, you will receive a current product in accordance with the stated specifications. Errors and omissions are excepted.
