VelotricThunder 1 Step-Thru

Loading..

Questions and Answers

Aluminum
352
Shimano Altus
28" / 700c
Diamond
Disc Brakes
E-Bike with a Little Extra. Built for Fun

General

  • Frame6061 Triple-Butted Aluminum Alloy Frame, Integrated Cable Routing, Internal Battery, Flat Mount Disc, Rack and Fenders Compatible
  • Weight*36lbs
  • Frame materialAlloy

Brakes

  • BrakeTEKTRO HD-R280 Hydraulic Disc Brake
  • Brake LeverTEKTRO HD-R280 Aluminum Alloy, with adjustable reach
  • Rotors160mm Front and Rear

Wheels & Tires

  • Wheels700c disc, Double-Wall Aluminum Alloy, Pinned (F) 24 Hole / (R) 28 Hole
  • Front HubNOVATEC Aluminum Alloy J-Hook Disc Hub,12x100mm Thru-Axle
  • Tires700×40c Ebike Puncture Resistant Tires

Cockpit

  • Stem6061 Aluminum alloy, 3D-forged alloy, 8-degree rise, 31.8mm clamp, Garmin mount compatible
  • GripsVELOTRIC Ergonomic Comfort Grips
  • Handlebar6061 Aluminum Alloy, Φ31.8mm, 680mm

Motor & Battery

  • Battery36V, 9.8Ah, 352.8Wh
  • Charger36V, 2.0A, Operates on 100V-240V AC, 50-60Hz
  • Battery Capacity352 Wh
  • Maximum Motor Support20 MPH, Class 1

Accessories

  • RackSupported, buy separately from VELOTRIC
  • StandAluminum Alloy
  • FenderSupported, buy separately from VELOTRIC
  • Front LightLight Sensing, 6V/3W/45Lux High-Output Integrated LED, Adjustable Angle

Groupset

  • Chain / BeltKMC Z8.3
  • PedalsPlastic
  • CassetteSHIMANO 8 Speeds, 11-32T
  • ShiftersSHIMANO M315-8
  • ChainringsPROWHEEL Pro Aluminum Alloy, 42T Narrow Wide Chainring
  • CranksetAluminum Alloy, 165mm
  • Rear DerailleurSHIMANO M310-8
  • GearingShimano Altus

Saddle

  • SaddleVelotric Comfort, Customized by SELLE ROYAL
  • Seat Post6061 Aluminum Alloy, 30.9 x 300mm

Suspension

  • Fork6061 Aluminum Alloy, Internal Brake Routing, 12x100mm Thru-Axle, 1-1/4” to 1-1/8” Tapered Steerer，Fenders Compatible

Disclaimer

Deviations between specified and installed components are possible depending on the delivery situation. Alternatively installed components correspond to the quality level of the specified components. The specified model year corresponds to the model series defined by the manufacturer and not necessarily the year of manufacture. As some models are produced unchanged over several years, the year of manufacture may vary. Irrespective of this, you will receive a current product in accordance with the stated specifications. Errors and omissions are excepted.
